爐--大圖.jpg "1000度大型回轉爐")
爐-主圖-1.jpg "1000度大型回轉爐")
爐-主圖3.jpg "1000度大型回轉爐")
爐-主圖.jpg "1000度大型回轉爐")
溫度 Temperature項目 Item |
1000℃ | ||
電壓 AC Voltage AC | 380V/50HZ | ||
最高工作溫度 Max Working Temperature |
1100℃ | ||
長期工作溫度 Long-term -Working Temperature |
1000℃ | ||
控溫精度 Temperature Control Accuracy |
±1℃ | ||
爐管材質 Furnace Tube Material | 310S Stainless steel | ||
加熱區長度 Heating Zone Length | 爐管直徑 400*加熱區 3000mm Furnace Tube Diameter400*Heating Area 3000mm | ||
爐管傾斜角度 Inclination Angle of Furnace Tube | 0-10 度可調 Adjustable from 0 to 10 ° | ||
喂料機旋轉 Feed Machine Rotation | 0-5 轉可調，采用變頻器，數顯調節 0-5 turn adjustable, using frequency converter, digital display adjustment | ||
爐管旋轉 Furnace Tube Rotation | 0-10 轉可調，采用變頻器，數顯調節 Adjustable from 0 to 10 revolutions, using a variable frequency drive with digital display control. | ||
密封 Seal | 進料口和出料口采用旋轉密封 The feed inlet and outlet adopt rotary seals. | ||
進氣口 Air Intake | 一個進氣口和一個氮氣流量計 One air inlet and one nitrogen flow meter | ||
控溫點 Temperature Control Point | 3 個，三套控溫系統 3 units, three sets of temperature control systems | ||
測溫元件及測溫范圍 Temperature Measuring Element and Range |
K 型熱電偶 Type K thermocouple | ||
編程曲線段數 Number of Programming curve segments |
30 段 | ||
爐體結構和材質 Furnace structure and material | 電爐爐體采用了先進的風冷雙層碳鋼爐體結構，有效的風冷導向隔板使?fàn)t殼整體冷風循環，最終冷卻發熱元件導電片后排出爐體，避免了發熱元件導電片的高溫氧化；保證了良好的工作環境。 The electric furnace adopts the advanced air-cooled double-layer carbon steel furnace structure, and the effective air-cooled guide partition circulates the whole cold air of the furnace shell, and finally cools the conductive sheet of the heating element and exits the furnace body, avoiding the high-temperature oxidation of the conductive sheet of the heating element. Ensure a good working environment. | ||
耐火保溫材料 Refractory insulation material | 爐襯使用真空成型高純氧化鋁聚輕材料制作而成，使用溫度高，蓄熱量小，耐急熱急冷、不裂縫、不掉渣、保溫性能好。 The furnace lining is made of vacuum forming high-purity aluminum oxide polymer material, which has high temperature, low heat storage, resistance to acute heating and cooling, no crack, no slag, and good thermal insulation performance. | ||
安全溫度控制 Safe temperature control | 采用閉環技術可控硅模塊觸發控制，移相觸發控制或者過零觸發方式，輸出電壓、電流或功率連續可調，具有恒電壓、恒電流或恒功率的特性；電流環為內環，電壓環為外環，在突加負載或負載電流超過限流值時，限制調壓器的輸出電流在額定電流范圍內，確保輸出和調壓器正常工作；同時電壓環也參與調節，使調壓器的輸出電流被限制在額定電流范圍內，在有充分調節余量的前提下維持輸出電流及電壓的恒定；從而到達保護發熱元件避免過大電流、電壓的沖擊， 達到安全可靠的控制效果及控制精度。 Closed-loop technology thyristor module trigger control, phase-shift trigger control or zero-crossing trigger mode, output voltage, current or power continuously adjustable, with constant voltage, constant current or constant power characteristics; The current ring is the inner ring and the voltage ring is the outer ring. When the load is suddenly added or the load current exceeds the current limit value, the output current of the voltage regulator is limited to the rated current range to ensure that the output and voltage regulator work normally. At the same time, the voltage ring is also involved in the regulation, so that the output current of the regulator is limited within the rated current range, and the output current and voltage are maintained under the premise of sufficient adjustment margin. Thus to protect the heating element from excessive current and voltage impact, to achieve safe and reliable control effect and control accuracy. | ||
升溫速率 Heating Rate | 1℃/h 至 20℃/min 可調 Adjustable from 1℃/h to 20℃/min. | ||
發熱元件 Heating Elements | 高溫硅碳棒 High temperature silicon carbon rod | ||
發熱元件位置 Locating of Heating Elements | 安裝位置爐管四周，與爐管水平 Installation position around the furnace tube, horizontally aligned with the furnace tube. | ||
溫度曲線設定 Temperature curve setting | 采用智能溫度控制儀，備標準 PID、人工智能調節 APID 或 MPT 等多種調節方式，具有自整定、自學習功能，無超調及無欠調的優良控制特性，具備 30段程序控制功能，可實現任意斜率的升、降溫控制，具有跳轉（循環）、運行、暫停及停止等可編程/可操作命令，并允許在程序的控制運行中隨時修改程序；采用具備曲線擬合功能的人工智能調節算法，能獲得光滑平順的曲線控制效果。 Intelligent temperature controller, equipped with standard PID, artificial intelligence to adjust APID or MPT and other adjustment methods, with self-tuning, self-learning function, no overshoot and no undermodulation of excellent control characteristics, with 30 program control function, can achieve any slope of rise and drop temperature control. It has programmable/operable commands such as jump (loop), run, pause and stop, and allows modification of the program at any time during the control operation of the program; Using artificial intelligence adjustment algorithm with curve fitting function, smooth curve control effect can be obtained. | ||
爐體溫度 Furnace Temperature | ≤45℃ | ||
計算機接口 Computer Interface | RS485 RS232 USB | ||
保修范圍及期限 Warranty Scope and Duration | 電爐免費保修一年，(發熱元件、爐管不保修) The electric furnace comes with a one-year free warranty, (heating elements and furnace tubes are not covered by the warranty). | ||
隨機配件 Random Accessories | 說明書一份，合格證一份，坩堝鉗一把，高溫手套一副 One instruction manual, one certificate of conformity, one crucible tong, and one pair of high-temperature gloves | ||
